Product Attributes Select All
Categories Integrated Circuits (ICs)
PMIC - Motor Drivers, Controllers
Manufacturer  Toshiba Semiconductor and Storage
Series  -
Packaging ? Tape & Reel (TR) ?
Part Status  Active
Motor Type - Stepper  -
Motor Type - AC, DC  Brushed DC
Function  Driver - Fully Integrated, Control and Power Stage
Output Configuration  Half Bridge (4)
Interface  Parallel
Technology  Power MOSFET
Step Resolution  -
Applications  General Purpose
Current - Output  1A
Voltage - Supply  2.7 V ~ 5.5 V
Voltage - Load  2.5 V ~ 13.5 V
Operating Temperature  -20°C ~ 85°C (TA)
Mounting Type  Surface Mount
Package / Case  24-LSSOP (0.220", 5.60mm Width)
Supplier Device Package  24-SSOP
