ACS758: Thermally Enhanced, Fully Integrated, Hall Effect-Based Linear Current Sensor IC with 100 µΩ Current Conductor

The Allegro ACS758 family of current sensor ICs provides economical and precise solutions for AC or DC current sensing. Typical applications include motor control, load detection and management, power supply and DC-to-DC converter control, inverter control, and overcurrent fault detection.

The device consists of a precision, low-offset linear Hall circuit with a copper conduction path located near the die. Applied current flowing through this copper conduction path generates a magnetic field which the Hall IC converts into a proportional voltage. Device accuracy is optimized through the close proximity of the magnetic signal to the Hall transducer. A precise, proportional output voltage is provided by the low-offset, chopper-stabilized BiCMOS Hall IC, which is programmed for accuracy at the factory.

High level immunity to current conductor dV/dt and stray electric fields, offered by Allegro proprietary integrated shield technology, guarantees low output voltage ripple and low offset drift in high-side, high voltage applications.

The output of the device has a positive slope (>VCC / 2) when an increasing current flows through the primary copper conduction path (from terminal 4 to terminal 5), which is the path used for current sampling. The internal resistance of this conductive path is 100 µΩ typical, providing low power loss.

The thickness of the copper conductor allows survival of the device at high overcurrent conditions. The terminals of the conductive path are electrically isolated from the signal leads (pins 1 through 3). This allows the ACS758 family of sensor ICs to be used in applications requiring electrical isolation without the use of opto-isolators or other costly isolation techniques.

The device is fully calibrated prior to shipment from the factory. The ACS758 family is lead (Pb) free. All leads are plated with 100% matte tin, and there is no Pb inside the package. The heavy gauge leadframe is made of oxygen-free copper.

Part Number Package Type Temperature RoHS
   Compliant
ACS758ECB-200B-PFF-T 3-lead CB -40°C to 85°C Yes

ACS758ECB-200B-PSF-T 3-lead CB -40°C to 85°C Yes

ACS758ECB-200B-PSS-T 3-lead CB -40°C to 85°C Yes

ACS758ECB-200U-PFF-T 3-lead CB -40°C to 85°C Yes

ACS758KCB-150B-PFF-T 3-lead CB -40°C to 125°C Yes

ACS758KCB-150B-PSF-T 3-lead CB -40°C to 125°C Yes

ACS758KCB-150B-PSS-T 3-lead CB -40°C to 125°C Yes

ACS758KCB-150U-PFF-T 3-lead CB -40°C to 125°C Yes

ASEK758KCB-150B-T DEMO BOARD -40°C to 125°C No

ACS758LCB-050B-PFF-T 3-lead CB -40°C to 150°C Yes

ACS758LCB-050U-PFF-T 3-lead CB -40°C to 150°C Yes

ACS758LCB-100B-PFF-T 3-lead CB -40°C to 150°C Yes

ACS758LCB-100B-PSF-T 3-lead CB -40°C to 150°C Yes

ACS758LCB-100U-PFF-T 3-lead CB -40°C to 150°C Yes

ASEK758LCB-050B-T DEMO BOARD -40°C to 150°C No

ASEK758LCB-100B-T DEMO BOARD -40°C to 150°C No
