Low-noise analog signal path

Device bandwidth is set via the new FILTER pin

5 µs output rise time in response to step input current

80 kHz bandwidth

Total output error 1.5% at TA = 25°C

Small footprint, low-profile SOIC8 package

1.2 mΩ internal conductor resistance

2.1 kVRMS minimum isolation voltage from pins 1-4 to pins 5-8

5.0 V, single supply operation

66 to 185 mV/A output sensitivity

Output voltage proportional to AC or DC currents

Factory-trimmed for accuracy

Extremely stable output offset voltage

Nearly zero magnetic hysteresis

Ratiometric output from supply voltage
